Punch! ViaCAD 2D/3D Alternatives

Punch! ViaCAD 2D/3D

Description
Punch! ViaCAD 2D/3D is the fine combination of both 2D and 3D designing making the users able to enjoy advanced level of designing features at one place. This advanced level of CAD software deliver the users with a stream less operation of both 2D and 3D to enjoy creation of advanced level of projects within few hours… read more

14 Punch! ViaCAD 2D/3D Alternatives & Similar Software

Free
1

1. BabaCAD

BabaCAD is a free CAD software only for the professionals for creating the 2D vector-based shapes, block, circle, hatch, georeferenced raster, etc. The reasons behind using the BabaCAD are the functions and advantages that it is offering to its users. This CAD program is designed for all type of users either professionals or students. It is the name of a straightforward and simple to use CAD program for all skill levels. The interface of the BabaCAD is user friendly so that you can get instant access to tools and available options easily. Its simplified user interface BabaCAD support for fast editing and saving of work with high precision. It is capable of reading DWG and DXF files and editing them as well. By default, BabaCAD itself save the work in DXF standard format. BabaCAD is fully customized with API and LISP that developers can use LISP scripts to customized BabaCAD. Moreover, BabaCAD installation includes API for programming BabaCAD extension modules. You can add new commands and functions for advanced features. Development platform for API is MS Visual C++. Developers can write .BEM module in just a few minutes. For advanced CAD users, LISP enabled CAD is must to have feature. As there are many available functions and scripts on the web, one can speed up and automate his drafting work with minimum programming knowledge. For those developers having knowledge of LISP programming, there are no limits in programming powerful lists for any purpose. In term of extension, BabaCAD is featured rich as it support for the multiple extensions.

Free
0

2. FreeCAD

FreeCAD is a free and open source 3D CAD modeler to workflow your architectural, molding and designing work in a smooth environment. If you are looking for a CAD program that will make you able to design the real-life objects whatever the size and type are the FreeCAD is a platform. The best about FreeCAD is that it offers the parametric modeling that is entirely different from the traditional modeling. Having parametric modeling means a system for easily modifying the structure of the design by going back into the model history and changing its parameters completely. FreeCAD is the name of a highly customizable, scriptable and extensible designing software for the Windows, Mac OS X, and Linux operating systems. In addition to working as a standalone program, FreeCAD is capable of working with the projects of other similar programs as well. If you have project stored in STEP, DAE, IGES, STL, OBJ and other related formats, then you can carry on the work on these by using FreeCAD. In short, FreeCAD will deliver you the really advanced features and functions along with the system of extending the features completely. The main technical features and functions of the FreeCAD are based on open CASCADE technology based geometry kernel for performing complex 3D operations, full parametric models, modular architecture to add functionality to the main application, support for all standard formats, sketcher to sketching of 2D shapes, robot simulation, drawing sheets module, rendering system, architecture module, etc.

Free
0

3. SketchUp Make

SketchUp Make is a best in the class CAD software capable of performing 2D and 3D rendering and designing, however, best for the 2D projects. SketchUp Make is particularly designed for the building sketching and performing architectural designing, however, can perform various other types of designing as well. It is one of the easiest and simplest ways that will provide you the highest and industry level of designing tools that you will ever witness in any other designing and CAD program. SketchUp Make is a free version of the SketchUp with limited features and functions as compared to the SketchUp Pro that is also the product of the SketchUp containing the most advanced level of features and functions. Kids, backyard, spaceship builders and all kind of other architects and designers can use this easy to use and best in the class 3D drawing tool that you will like to go with. The features or advantages that you will enjoy in the SketchUp Make are the creation of 3D models of all objects/projects, customizable interface to reflect the way you work, share created 3D models with others, imports the files from other 3D modeling programs or tools, and much more. SketchUp Make has some limitations as well. Means there are many features that you may not be able to enjoy in the SketchUp Make. The features that are not available in the SketchUp Make are the creation of multi-page presentation sets, production of construction drawings, full-screen presentation system, the addition of custom attributes and behaviors, generation of lists and reports, using of solid modeling tools, working with simulated film cameras, etc.

Free
0

4. OpenSCAD

OpenSCAD is a universal 3D CAD modeler for the professional programmers and designers to enjoy developing of solid 3D CAD objects within minimum possible time. This free software with all its features and functions is available for the Windows, Mac OS X, and Linux operating systems. The unique quality of this CAD program is that it is based on the programming featured 3D modeling where in addition to using the ready to use objects and design the users can create the new objects by way of programming as well. It is one of the best and great sources for learning the CAD coding as well. It will split the screen into two windows; one will displaying the work you are doing and the other showing the codes of work you are doing. OpenSCAD is much different from the most of the traditional and modern day CAD software because of not focusing on the artistic aspects of 3D modeling rather focus on the CAD aspects. So, it may be the CAD system you are searching for when you are planning to create the 3D models of the machine parts but pretty sure not what you are looking for when you are more interested in creating computer-animated movies. For the information of the readers, OpenSCAD is not an interactive modeler rather it is a like 3D compiler that reads in a script file that describes the objects and renders the 3D model from the script file. That system of OpenSCAD will give you full command and control over the entire modeling process and make you able easily to change any step in the modeling process or make the designs that are defined by configurable parameters.

Free
0

5. KiCAD

For the first time, there is a CAD program that is designed for electronics and electrical designing and architecting only. It will make the electronics and electrical engineers able to easily make the PCB circuits and simple electronic circuits based on its advanced features. This software suite is solely for the electronic design automation so don’t bother to consider it for other development purposes. The working system of KiCAD divided into three parts that are schematic capture, PCB layout, and 3D viewer. Schematic capture is for creating the design without any limitation. The features listed in this section or endless containing no paywalls at all. The official library of KiCAD contains the symbols and editor to make you able design your product as you want. The special PCB layout area of KiCAD is to make the designers able to make professional PCB layouts with up to thirty-two copper layers. For the assistance and easiness of the designers, the recent version of KiCAD contains a push and shove router that is capable of routing differential pairs and interactively tuning trace lengths. KiCAD also includes a 3D view that you can use to inspect the design in an interactive canvas. It will make the process of rotating and panning around to inspect details that are otherwise difficult to inspect on a 2D view. The multiple rendering systems in the KiCAD will make you able to modify the aesthetic appearance of the board or to hid and show features for easier inspection. KiCAD is a great source of designing for the electrical and electronics engineers.

Free
0

6. QCAD

QCAD is an open source two-dimensional CAD system for the Windows, Mac OS X, and Linux operating systems. For all these leading platforms, QCAD is available for free with all its features and functions. By using this program you can easily create the technical drawings like building plans, interiors designing, structuring of mechanical parts or schematics and diagrams. Modularity, portability, and extensibility are the some advantages of using the QCAD. QCAD is the name of an easy to use yet comprehensive 2D CAD system for each type of architecture and designers. As it comes in ready to use format so doesn’t require any configuration at all. QCAD is capable of generating CAM particular output for use on a CNC machine. It can be even customized to generate virtually any output from any given CAD file. That system of QCAD is made possible because of the new ECMAScript based output configuration system. This CAD software includes almost all those features and tools that will make you able to enjoy the system of exporting drawing to machine readable formats like G-Code. These types of files are mostly used to control CNC like engraving machines, milling machines, or water jet cutting machines. Some features and functions of the QCAD are advanced layering system, blocking/grouping system, availability of 34 CAD fonts, support for TrueType fonts, availability of imperial and metrical units, DXF/DWG input and output system, printing on multiple pages, availability of modification and construction tools, various powerful entity selection tools, object snaps, measuring tools, and much more. QCAD has a complete and extremely powerful ECMAScript scripting interface.

Free
0

7. LibreCAD

LibreCAD is the name of a free and open source 2D CAD program for the iDevices and Windows and Linux operating systems. For the entire assistance of the users, the free version of LibreCAD even supports for the system of assistance by its community of developers. You can contribute to the development of LibreCAD if you have technical programming knowledge. LibreCAD itself is based on Qt that is called as the leading cross-platform application and user interface development framework. This CAD program is capable of reading DWG, DXF, and other supported files. If you have work created by other CAD programs and saved in the supported format of the LibreCAD, then you can simply import that project into the LibreCAD for further working on it. It itself is capable in writing DXF file. However, in term of exporting files it doesn’t support for both formats but support for exporting in image based file formats. It has a proper layer, blocks, splines, advanced tangent line, transformation tools, advanced snapping system and much more. Because of focusing more on the 2D geometry only that’s why LibreCAD is very responsive and lightweight CAD program. LibreCAD is a fully comprehensive 2D CAD application that you can download and install for free. The main technical features of LibreCAD that are simply the great advantages of LibreCAD are totally free and no subscription system at all, availability in various international languages and much more. You can also contribute to the development of the LibreCAD as well.

Free
0

8. NanoCAD

NanoCAD is a free CAD program with the support of the DWG format. Either it is about creating new project or working on the existing project designed by the other CAD program, NanoCAD is capable of dealing with both. In addition to various other supported formats, if you have the file saved in DWG format then you can simply import in the NanoCAD for further working on it. The latest version of NanoCAD offers improved interface to provide comfortable and clean for users’ work. It is based on the need of the end users that offers an unbeatable combination of cost, capacity, capability and quality. It has improved document processing features to simplify your world with drawing. It has the house of all those features and tools that you really need. The support for additional modules in the NanoCAD makes the users able to extend its features and functions to get more advancement in its way of functioning. Some of the great feature and functions of the NanoCAD are optimization and anti-aliasing, drawing preview file system, improved file control, convenient file opening system, the contextual menu of drawing, settings for dynamic object highlight, and easy selection of overlapping objects. Most of the designers often work with drawing containing a large number of objects. They require using selection to work efficiently. NanoCAD has a new selection dialog for overlapping objects. You can now select multiple items in any combination. It will tell make you able to choose what kind of object you are selecting and dynamically highlighting them, pointing the names of layers that are selectable.

0

9. PTC Creo CAD

Based on the features of developing parametric to apps specializing in direct modeling, PTC Creo CAD has the solution of all of your issues. This CAD software support product design for discrete manufacturers. It consists of multiple features in a single pack each providing different set of capabilities as per the individual product development of the users. Parametric, 3D designing, 2D designing, simulation, and visualization are the some main advantages of the PTC Creo CAD. With the product of PTC Creo CAD, you can take your product from concept to digital prototype and do so with accuracy, efficiency and measure of grace. All designing products of the PTC Creo CAD are intuitive and all works together. From the comprehensive capabilities of PTC Creo CAD Parametric to tools specializing in direct modeling, PTC Creo CAD has all those features and functions that you need. Whether you are looking for speed and flexibility in CAD software for the better ending of the project you are doing or you are at the initial stages of concept designing, the direct modeling system of PTC Creo CAD will make you able to work efficiently with geometry quickly and easily. Use PTC Creo CAD to capture initial ideas and leverage 2D data to 3D product models that accurately reflect design intent. PTC Creo Schematics of PTC Creo CAD will make you able to create 2D schematic designs of routed systems and meets the 2D needs of the engineers and designers. Now you can resolve basic design issues in engineering before handing off your product to analysis.

0

10. DesignCAD 3D Max

DesignCAD 3D Max is the name of easy to use and simple 2D/3D CAD software ideal for the professionals and perfect for the beginners. Based on the simplicity but powerful features at the same time DesignCAD 3D Max is the best in the class designing software that is capable in high quality designs and performing simple to high rendering. DesignCAD 3D Max combines the features of 2D and 3D so that you can carry out the working of 2D and 3D at a centralized platform instead of going for using two different set of programs. Check out some tools and rendering features available in the DesignCAD 3D Max; precision 2D drafting tools, 3D solid modeling tools, mechanical design tools, architectural design tools, realistic rendering, intuitive user interface and extensive online help. The program is widely available for both 32-bit and 64-bit versions of the all editions of the Windows operating systems. The straightforward and easy to use intuitive interface of DesignCAD 3D Max make it possible for the users to design 2D drawings fast and easy. It will make you able to create complex 3D shapes by simply extruding from 2D shapes. The advanced rendering system of DesignCAD 3D Max will make allow you to apply a wide range of textures, symbols, colors, materials, brush styles and much more. The users can even customized the material textures to further enhance the realism. The main technical features and functions of the DesignCAD 3D Max are versatile 2D/3D CAD solution, easy to use 2D design & drafting, precision 3D modeling, realistic visualization & lighting, accelerate drawing performance, layers system, 3D model content for simple architectural design, availability of various structure models, etc.

0

11. SOLIDWORKS 3D CAD

Punch! ViaCAD 2D/3D is the fine combination of both 2D and 3D designing making the users able to enjoy advanced level of designing features at one place. This advanced level of CAD software deliver the users with a stream less operation of both 2D and 3D to enjoy creation of advanced level of projects within few hours. Punch! ViaCAD 2D/3D is particularly designed for the engineers, architects and designers. Punch! ViaCAD 2D/3D is simply the best and perfect way to take your sketched ideas to 3D realism. Punch! ViaCAD 2D/3D is the fine place of expert features that will make the process of designing easy and straightforward for you. Have a glance on what Punch! ViaCAD 2D/3D is offering. A texture library containing hundreds of ready to use materials, history-based modeling, twisting & bending system, NURB surfaces, design variations, system for creating detail plan and plan sheets, convert 2D profiles into 3D, auto generate system to automatically 2D creation, presentation options, etc. just like its straightforward interface, Punch! ViaCAD 2D/3D itself has made the process of solid and other type of modeling easy and simple. This CAD software deliver a seamless integration of both 2D and 3D to make you able to get full command and control on your sketched ideas to reality. Punch! ViaCAD 2D/3D is based on the professional level of technology providing the best speed, precision and compatibility at a centralize place. Within a minutes you can see the product by yourself in 3D modes that you are creating. The integration of LogiCurosor technology has make the work of designers simple because it anticipates your moves and shows a suggested action you draw.

Free
0

12. Autodesk 123D

Autodesk 123D is a free 3D modeling software for both 2D and 3D modeling and making the DIY projects. This software integrates the features and functions of the sharing and collaboration with the other team members in case of a joint project. Options available at the Autodesk 123D are surely endless. Autodesk 123D is for those who want to make the 3D models and other objects by their selves. However, it itself is listed with a lot of 3D models as well so that the users can easily craft their projects without going for creating the models first. Autodesk 123D is a free and straightforward CAD software that is integrated with the both content and fabrication services. For the first time there is a CAD program that will make you able to generate 3D models from the photos. Have you any idea in your mind about creating claws, hands, feet, wings, fins or paws and want to visualize them like a pro then Autodesk 123D is the name of an easy to use CAD software that will make you able to create the incredible 3D sculptures from the scratches. Drawing by using Autodesk 123D is really simple that start from basic skeleton. The skeleton and sculpt maker of Autodesk 123D will assist you in creating 3D sculptures as easy as drawing a stick figure. Drag joints to create new limbs or adjust their thickness and position. In the sculpting area you can refine the surface shape using a wide range of tools. You can perform as many functions about sculpt in or out, smooth, sharpen and flatten until you sculpture is complete.

0

13. BRL-CAD

BRL-CAD is an open source solid modeling platform for rendering and geometric analysis and making advanced level of creative projects. BRL-CAD is equally useful for engineers, designers, gamers and architects as it support for solid modeling creating for all. BRL-CAD is based on the BRL-CAD Kernel and Hybrid CSG along with innovative methods for unambiguous 3D geometry that is regarded as the best for validation, verification and performant. This powerful solid modeling program is integrated with the an interactive geometry editing, high performance ray tracing for rendering and geometric analysis and a system performance analysis benchmark suite, and a proper geometry library for application developers. In short, features and tools for creating the solid models are simply endless here. BRL-CAD support a large variety of geometric representations including an extensive set of traditional CSG primitive implicit solids like ellipsoids, boxes, cones, tour and also the explicit solids made from closed collections of NURBS and Uniform-B surface and purely faceted mesh geometry. All geometric objects available in the BRL-CAD may be combined using Boolean set-theoretic CSG operations including union, intersection and difference. This platform is a collection of multiple applications, utilities and tools comprising million lines of source code. BRL-CAD is basically designed to be extensively cross-platform and is actively developed on and maintained for many common operating systems including Windows, Mac OS X, Linux, BSD, Solaris among others. In addition to free, BRL-CAD is an open source CAD platform that means you can enjoy the customization of its setting according to your requirements.

0

14. Solidworks

Solidworks is a CAD (computer-aided design) software that allows you to create, simulate, publish and manage 3D model. It is a powerful solution available to use MAC and Microsoft Windows operating system. The technology intends to make engineering processes more efficient with tools for conceptual designs, layout and dynamic analysis etc. It has rich simulation capabilities to help you to test product performance against real-life circumstances. Solidworks analytical properties also help identify and resolve complicated assembly issues during the early stages of product development. It also offers lots of new tools and functionalities that make your product enhanced. A 3D solid modelling feature provides lifelike visualization and pre-manufacturing virtual testing; this helps make products development more productive and help reduce costs. You can create a variety of sheet metal part design using specialized and flexible tools. Large assembly design, automatic drawing view creation and update, mould design, CAD import and export, revision control and advanced surface design these are core features of the solution. Solidworks offers different price plans; each plan has its own features and benefits. Try it out; you’ll be amazed at all the thing in this stunning platform.
